Mini-Mac Applicator for CP2.8 and CPX2.8 Crimp Terminals
NOTES
1. Molex recommends an extra perishable tooling kit be maintained at your facility.
2. Verify tooling alignment by manually cycling the press with applicator before crimping under power. Check that
all screws are tight.
3. Slugs, terminals, dirt, and oil should be kept clear of work area.
4. Wear safety glasses at all times.
5. For recommended maintenance refer to the Mini-Mac Applicator Manual (Document no. 63880-0000).
CAUTION : This applicator should only be used in a press with a shut height of 135.80 mm (5.346”).
Tooling damage could result at a lower setting.
CAUTION : To prevent injury, never operate this applicator without the guards supplied with the press or
wire-processing machine in place. Reference the press or wire processing manufacturer’s instruction
manual.
CAUTION : Molex crimp specifications are valid only when used with Molex terminals, applicators and
tooling.
Contact Information
For more information on Molex application tooling please contact Molex at 1-800-786-6539.
Americas Headquarters
Lisle, Illinois 60532 U.S.A.
1-800-78MOLEX
amerinfo@molex.com
Far East North Headquarters
Yamato, Kanagawa, Japan
81-462-65-2324
feninfo@molex.com
Far East South Headquarters
Jurong, Singapore
65-6-268-6868
fesinfo@molex.com
European Headquarters
Munich, Germany
49-89-413092-0
eurinfo@molex.com
Corporate Headquarters
2222 Wellington Ct.
Lisle, IL 60532 U.S.A.
630-969-4550
Fax: 630-969-1352
Visit our Web site at http://www.molex.com
Doc No: ATS-638950900
Revision: D
Release Date: 10-21-08
Revision Date: 03-24-10
UNCONTROLLED COPY
Page 5 of 5
